1, Adopting automatic feeding, box opening, box into the box, batch number, box sealing, scrap and other packaging
Form, compact and reasonable structure, simple operation and adjustment;
2, servo/stepper motor and touch screen, PLC programmable control system, man-machine community;
Surface display operation more clear and simple, high degree of automation, more user-friendly;
3, the use of photoelectric eye automatic detection and tracking system, empty bag no box, to maximize the section
About packaging materials;
4, the packaging range is large, easy to adjust, various specifications and sizes can be quickly converted;
5, the replacement specifications do not need to replace the mold, just adjust can be achieved;
6, using items into the box is not in place automatic stop and the main drive motor overload protection device,
More safe and reliable application;
7, according to customer requirements, the use of upturning safety cover, easy to operate, shape
Beautiful.
8, can be used with aluminum-plastic packaging machine, pillow packaging machine, three-dimensional packaging machine, bottle line, filling
Machine, labeling machine, inkjet machine, online weighing instrument, other production lines and other equipment
Linkage production;
9, according to the requirements of the packaging design of a variety of automatic feeder and box system;
10, can be selected according to customer requirements hot melt glue machine, using hot melt glue spray sealing box.
|
主要技术参数(Main parameter)： |
|
项目/型号(ltem/Model) |
JX-120Z |
|
包装速度(Packing speed) |
20-100 cartons/min |
|
纸盒尺寸范围(Size range of carton) |
L(70-200)×W(30-90)×H(15-70)mm |
|
纸盒纸质要求(Paper quality of carton) |
250-400g/M² |
|
电机功率(Motor Power) |
1.5KW |
|
电源类型 (Power supplu type) |
220V-/380V |
|
机器噪音(Machine noise) |
≤80dB |
|
气源(Air supply) |
0.5-0.8 Mpa |
|
耗气量(Air consumption) |
120-160L/min |
|
外形尺寸(Dimensions) |
L3280×W1200×H1700 mm |
|
整机重量 (Total Weight) |
1200Kg |
